The Jinan Changhao High-Efficiency V-Shape Ditching Buckets (Trapezoidal Buckets) are precision-engineered for the construction and maintenance of canals, drainage ditches, and pipelines. Our unique V-profile design allows operators to form perfect bank slopes in a single pass, eliminating multiple digging cycles and significantly reducing labor costs. Whether you are working on large-scale irrigation projects or road-side drainage, our buckets ensure a smooth, professional finish every time.
The wide range produced means that a suitable piece of equipment is available for all applications.
A wide range of V-buckets is available thanks to the possibility of sloping the sides on request.
Bucket essential for road construction and environmental restoration companies.
Slope the ditch with every pass and eliminate digging cycles.
Available in virtually any width and slope angle.
| Key Features | Specifications / Options |
|---|---|
| Available Slope Angles | 45°, 50°, 60°, or Customized |
| Bottom Width Range | 300mm to 1200mm (Based on tonnage) |
| Carrier Class | 3 – 45 Ton Excavators (Mini to Heavy Duty) |
| Main Body Material | High-Strength Q355B Steel |
| Cutting Edge Material | NM400 Wear-Resistant Steel |
| Drainage Option | Optional side drainage holes available for wet clay |
Wear-Resistant Side Armor: We use reinforced side cutters made of NM400 alloy steel to withstand the high friction encountered during trenching in hard or abrasive soils.
Customized Wing Design: The top width and slope angle are tailored to match your specific engineering requirements for irrigation or landfill projects.
Heavy-Duty Gussets: Reinforced structural gussets prevent the bucket’s wings from bending under heavy lateral loads during deep ditching.
Factory-Direct Mounting: Customized bracket fabrication based on your machine’s Pin Diameter, Center Distance, and Ear Width to ensure a 100% gap-free fit.
Perfect fit for major excavator brands:
CAT: 305, 308, 312, 320, 330, 336 series.
Sany: SY75, SY135, SY215, SY365.
Komatsu, Volvo, Hitachi, JCB, Hyundai, and more.
