hydraulic breaker for mini excavator
Hydraulic Breaker Hammer-Warranty 12 months
Hydraulic Breaker Hammer for 1~90 Tons Excavator
Q: Are you sure your hydraulic breakers will fit my excavator?A: Yes, we sure. We have more than 20 years experience in manufacturing hydraulic breakers. Our hydraulic breakers are suitable for excavators of VOLVO, Hitachi，Komatsu，Doosan, Susitomo,SANY, Cat,KOBELCO,XCMG. Show us your excavator model, we’ll confirm the solution.
Q: How about your products warranty?A:12 months warranty for hydraulic breaker, Free replacement will provide once the failure confirmed caused by our product quality. Beyond the warranty period,Our sales team and Technical Support will response for your question within 24 hours (Holidays Excluded).
Q: Can you produce according to customers’ design?
A:Sure, OEM/ODM service available. We are professional in manufacturing and assembling hydraulic breakers.
breaker parts
hydraulic breaker type
| No. | Model | UNIT | SB05 | SB10 | SB20 | SB30 | SB40 | SB43 | SB45 |
| 1 | Weight | Kg | 70 | 70 | 130 | 170 | 300 | 400 | 500 |
| 2 | Length | mm | 1000 | 1000 | 900 | 1000 | 1100 | 1300 | 1450 |
| 3 | Working Pressure | kg/cm² | 90~120 | 90~120 | 110-140 | 110-140 | 110-160 | 110-160 | 120-170 |
| 4 | Oil Flow | L/min | 15~25 | 15~25 | 25-40 | 25-45 | 30-45 | 35-65 | 45-85 |
| 5 | Impact Rate | bpm | 700~1200 | 700~1200 | 550-1000 | 500-900 | 500-800 | 500-700 | 400-700 |
| 6 | Oil hose dia. | inch | 3/8 | 3/8 | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 |
| 7 | Chisel Dia. | mm | 35 | 40 | 45 | 53 | 68 | 75 | 85 |
| 8 | Chisel Weight | kg | 5 | 5 | 5 | 7.5 | 15 | 23 | 40 |
| 9 | Bucket Capacity | m³ | 0.1 | 0.1 | 0.1 | 0.1 | 0.15-0.25 | 0.25-0.35 | 0.25-0.5 |
| 10 | Excavator | ton | 1~1.2 | 1~1.5 | 1.5-2.5 | 2.5-3.5 | 3.0-7.0 | 6.0-8.0 | 7.0-14 |
| No. | Model | UNIT | SB50 | SB70 | SB81 | SB100 | SB121 | SB131 | SB151 |
| 1 | Weight | Kg | 800 | 1700 | 1800 | 2400 | 2600 | 3100 | 4100 |
| 2 | Length | mm | 1500 | 1600 | 1700 | 2800 | 3300 | 3500 | 3800 |
| 3 | Working Pressure | kg/cm² | 150-170 | 180-200 | 180-200 | 180-200 | 200-250 | 200-250 | 220-280 |
| 4 | Oil Flow | L/min | 80-120 | 120-160 | 130-170 | 150-190 | 170-220 | 120-160 | 120-160 |
| 5 | Impact Rate | bpm | 400-700 | 400-700 | 400-600 | 350-500 | 250-400 | 400-700 | 400-700 |
| 6 | Oil hose dia. | inch | 3/4 | 1 | 1 | 1 | 1 1/2 | 1 1/2 | 1 1/2 |
| 7 | Chisel Dia. | mm | 100 | 135 | 140 | 150 | 155 | 165 | 175 |
| 8 | Chisel Weight | kg | 48 | 115 | 126 | 182 | 195 | 205 | 210 |
| 9 | Bucket Capacity | m3 | 0.45-0.6 | 0.6-0.8 | 0.7-0.9 | 1.1-1.4 | 1.1-1.7 | 1.2-1.7 | 1.3-1.8 |
| 10 | Excavator | ton | 11-16 | 19-26 | 19-26 | 27~38 | 28-40 | 30-45 | 30-45 |
Jinan Changhao Machinery Equipment Co., Ltd. located in Workshop 24, East End of Gangyuan Second Road, No. 33688, Jingshi East Road, Jinan Area of China(Shandong ) Pilot Free Trade Zone, Jinan, Shang dong, China. The workshops occupy an area of 3,000 square meters. The bonded area is supported by national preferential policies and resources are inclined. There is superior terrain, beautiful environment and convenient transportation.
Our company specialized in manufacturing all kinds of hydraulic breaker hammer，breaker hammer pipeline and their accessories as well as excavator attachments, breaker parts has hydraulic breaker piston, Front & Back head, cylinder, Thrust & Outer bushings, Hammer drill rod and flat pin, Valve and valve, code Seal housing and so on. All the accessories of our pipeline, including clamps, ball valve, foot valve, wire plug, wire alignment, relief valve, lock valve, bracket, connector, hammer tube, arm iron pipe assembly, three-way iron pipe, are independently developed and manufactured by our factory to ensure product quality, safety and reliability.
We have perfect production equipments and test devices. Our company has various international certifications and adopts advanced technology to ensure product quality. We strictly control the material of our products, adopting unique heat treatment technology, special alloy materials, and the quality has reached international advanced level.
Jinan Changhao Machinery Equipment Co., Ltd.
Besides hydraulic breaker hammer, we also provide hydraulic breaker parts.
hydraulic breaker and hydraulic breaker parts
