Skid steer hydraulic concrete breaker is essential attachment for skid steer loader. HWX skid steer concrete breaker is engineered to efficiently break through hard and compact materials such as concrete, rock, and asphalt. It is an indispensable tool for demolition, construction, quarrying, and trenching applications. Our breakers are built with a robust housing and a high-strength piston to maximize impact energy while protecting both the attachment and the carrier machine from damaging shock loads.
Key Features of HWX hydraulic breaker hammer:
High Impact Energy & Frequency: Delivers maximum breaking force for rapid material disintegration.
Robust Construction: Our hydraulic breakers are made of heavy-duty steel housing and hardened piston for superior durability in tough conditions.
Easy Installation & Compatibility: Standard universal mounting interface for quick attachment to most skid-steer loaders.
Minimal Noise & Vibration: Designed for more efficient and operator-comfortable performance.
We provide OEM Service and customized logo service. Welcome to visit our factory and to be our wholesalers.
Parameters of HWX hydraulic breaker hammer
| Model | UNIT | HWX450 | HWX530 | HWX680 |
| Weight | Kg | 130 | 170 | 300 |
| Length | mm | 900 | 1000 | 1100 |
| Working Pressure | kg/cm² | 110-140 | 110-140 | 110-160 |
| Oil Flow | L/min | 25-40 | 25-45 | 30-45 |
| Impact Rate | bpm | 550-1000 | 500-900 | 500-800 |
| Oil hose dia. | inch | 1/2 | 1/2 | 1/2 |
| Chisel Dia. | mm | 45 | 53 | 68 |
| Chisel Weight | kg | 5 | 8 | 17 |
| Bucket Capacity | m³ | 0.1 | 0.1 | 0.15-0.25 |
| Excavator | ton | 2.5~4.5 | 3.0~5.5 | 4.0-7.0 |
